Gotchas — what will surprise you, why, and what to do ​

Every entry is a recorded finding from building the plugin's own demos and reference HUD — none is speculative. Format: symptom → cause (with the source that proves it) → what to do. Perf-shaped entries cross-reference perf-guide.md; RCSS surface questions go to rcss-matrix.md.

Authoring: styles and layout ​

1. Your first document collapses into one line. Cause: RmlUi ships NO user-agent stylesheet — div defaults to display: inline, margins are 0 (Content/DevUI/M5Hud/vacuus-base.rcss:4-8 documents this exactly). Do: link vacuus-base.rcss FIRST in every document (the CLI template ships it: Web/packages/cli/template/vacuus-base.rcss), then your own sheets after it.

2. box-shadow does not render at all — and it is not just the transition. Symptom: the shadow never appears. The element itself is fine: it renders its normal background and border, exactly as if you had not written the property. One Warning per view names the property and the substitute. Cause: RmlUi builds a box-shadow by rendering it into an off-screen layer and asking the renderer to hand that layer back as a texture — SaveLayerAsTexture (Source/ThirdParty/RmlUi/Source/Core/GeometryBoxShadow.cpp:241). VaCuus has no layer render targets: PushLayer/CompositeLayers/PopLayer are recorded and then skipped at replay, so there is no layer to capture. Implementing the capture alone would not help — the shadow's blur is a filtered composite, and that is not applied at replay either, so the shadow would come out hard-edged. Refusing is the honest answer for v1. Do: use decorator: ninepatch(...) with a pre-blurred shadow image (the standard game-UI substitute, and cheaper), or font-effect: glow for text. Older builds also flashed the shadow in the view's top-left corner. RmlUi draws the shadow into its layer before asking for it back, and with the layer skipped those draws reached the screen at texture coordinates, once per new shadow value — so a shadow set on :hover flashed there on every hover. The refusal now discards them (VaCuus.Render.LayerCapture.RefusedDrawsDiscarded, fixed 2026-09-17). Also, separately: a box-shadow TRANSITION does nothing even where shadows render — RmlUi refuses the key at animation start with a Warning, not an error (Source/ThirdParty/RmlUi/Source/Core/ElementAnimation.cpp:640-648), and vacuus lint catches it at authoring time (Web/packages/cli/lib/lint.mjs:68-99). If you are reading an older copy of these docs that said only "not animatable": that was wrong about the bigger half. Fixed 2026-08-05 (bead VaCuus-u0q), which also fixed the plugin — until then a shadowed element rendered as an opaque WHITE rectangle over its own background and border, and forced a published frame on every single tick.

2b. mask-image parses and does not mask. Symptom: the element renders unmasked, as if you had not written the property. One Warning per view. Cause: the same wall as #2, one door along. RmlUi draws the mask decorators into a pushed layer and asks for that layer back as a filter — SaveLayerAsMaskImage (Source/ThirdParty/RmlUi/Source/Core/ElementEffects.cpp:306). With no real layer there is nothing to hand back, so the composite runs with no mask filter (bead VaCuus-iuv); the refusal discards the mask artwork's draws. Do: bake the alpha into the image asset and use decorator: image or ninepatch, or clip with overflow: hidden plus border-radius. Older builds painted the mask artwork over the element: with the layer skipped, those draws landed in the frame like any other geometry. Fixed 2026-09-17, same test as #2.

3. transition: opacity 0.3s ease-in-out; drops the ENTIRE declaration — there is no ease family in RmlUi. Cause: the complete tween keyword table is eleven families — back bounce circular cubic elastic exponential linear quadratic quartic quintic sine, each with -in, -out and -in-out (Source/ThirdParty/RmlUi/Source/Core/PropertyParserAnimation.cpp:27-77). No ease, no ease-in, no ease-out, no ease-in-out. A token that is not in that map is not a tween, so ParseTransition tries the other two shapes: the %fs sscanf for a duration fails (:267), and the property-name branch gets null from both GetShorthand and GetProperty, which returns false (:301-315). One false return discards the whole transition property — not just the bad token — and RCSS reports it as a single generic line:

Warning: [Rml] Syntax error parsing property declaration 'transition: opacity 0.3s ease-in-out;' in 2d6/components.rcss: 16.

Measured in a running engine with the two spellings side by side in one sheet: ease-in-out produced that warning and no transition; cubic-in-out was silent and applied. Do: cubic-in-out is the closest thing to CSS's ease-in-out — that is the direct substitution when you port a browser stylesheet. And write tween keywords lowercase: animation lowercases each token before the keyword lookup (:133) and transition does not (:240), so Cubic-Out animates fine and silently kills a transition. The canonical property-duration-tween order still holds; the lint pass is the backstop for box-shadow only, not for this.

3b. transition: opacity var(--t-fast) cubic-in-out; — the other silent way to lose a whole transition. FIXED 2026-08-06 in the vendored tree; read this if you build against stock RmlUi or are wondering why an older build never animated. Symptom: identical to #3 — the element snaps — but with no warning at all, not even the generic syntax-error line #3 gives you. Nothing in the log, at any level, in a debug build. Cause: a value containing var() is stored unparsed, as Property{value, Unit::VAR_EXPRESSION} (Source/ThirdParty/RmlUi/Source/Core/PropertySpecification.cpp:260-267), and resolved at compute time. That late resolution is exactly why var() works for every other property — and transition is the one property read before it, deliberately: ElementStyle::TransitionPropertyChanges takes the local property "to intercept property changes even before the computed values are ready" (ElementStyle.cpp:388) and then dropped anything that was not already a parsed transition list. A raw string is not, so the whole declaration vanished.

It is not exotic, it is the recommended idiom: RCSS has no calc(), so var() is the only theming layer rcss-matrix.md can point you at, and timing tokens in custom properties are the first thing anyone does with it. In the plugin's own 2d6 demo it killed ~30 transitions across four component batches and three screens, through a screenshot-reviewed component catalogue, and went unnoticed for days.

animation was never affected — its own value may contain var() and always could, because it is read through ComputedValues::animation(), which resolves (ComputedValues.cpp:8-16). So did var() inside @keyframes values. Only transition.

Do: nothing, on this plugin — the vendored tree resolves it now (Source/ThirdParty/RmlUi/VENDORED_TAG.txt, patch #4; bead VaCuus-6gj), pinned by VaCuus.Core.Style.TransitionVariable, which reports expected opacity 1.0000, got 0.2500 the moment that patch goes missing. On stock RmlUi, spell transition timings as literals. Either way #3 still applies to the tween keyword, and the two traps stack: a var() that substitutes to a value containing ease-in-out fails at #3 instead, which at least logs.

4. position: absolute lands somewhere unexpected. Cause: it resolves against the nearest ancestor with position: relative|absolute — there is no browser-style default-positioned root chain past the document (vacuus-base.rcss:29-31). Do: put position: relative on the container you mean to anchor to.

5. Text renders nothing; the log repeats "No font face defined" — and your own @font-face src resolves against the wrong directory. Cause: there is no default font (vacuus-base.rcss:32-36), and the message repeats per layout pass. The plugin loads LatoLatin for you and nothing else.

And LatoLatin is Latin-only. Measured coverage: U+0020–007E, U+00A0–017F, plus assorted symbols. No Cyrillic, no CJK, no Greek beyond a few maths glyphs. A game that ships a second language and does nothing about fonts renders that language as replacement boxes — see the whole story, with the switch recipe, in localization.md §6.

There are two routes to your own faces. @font-face in RCSS, below, is the authoring one. UVaCuusSubsystem::LoadFontFace(VfsPath, bFallbackFace) is the runtime one, for a game that only knows which face it needs once the language is chosen; it is idempotent and survives a UI-thread restart. (An earlier edition of this entry said there was no public C++ font API. That was true until the runtime door landed.)

Its src is ROOT-relative, which is the opposite of every other path in the system.<link> and <script src> are document-relative (#12); @font-face's src is passed verbatim with no JoinPath (StyleSheetParser.cpp:561) and handed straight to the file interface (FontEngineDefault/FontProvider.cpp:94), which resolves it against the ordered document roots (Source/VaCuus/Private/VaCuusContentPaths.cpp:92-103). So a sheet at Content/DevUI/myapp/app.rcss links its neighbours bare but must spell its fonts from the ROOT:

css
@font-face {
	font-family: "Michroma";       /* required, a quoted string */
	src: myapp/fonts/Michroma-Regular.ttf;   /* ROOT-relative; bare path, NO url() */
	font-weight: normal;           /* optional: all | normal | bold | <number>; default all */
	font-style: normal;            /* optional: normal | italic */
}

The grammar is StyleSheetParser.cpp:294-330 (properties) and :525-564 (the block): font-family and src are required, src is a comma-expanded list of bare paths — url() is not part of it, and -rmlui-fallback-face and -rmlui-face-index are the two RmlUi extensions. The control run that settles the resolution rule: from a subdirectory sheet, a bare Michroma-Regular.ttf gave Failed to open file 'Michroma-Regular.ttf' (resolved to …/Content/DevUI/Michroma-Regular.ttf).

font-weight: bold over LatoLatin draws REGULAR — the plugin ships one face. RmlUi picks the nearest weight a family has and never fakes a bold (FontEngineDefault/FontFamily.cpp:23-46), so every bold rule over the plugin's font renders regular. It used to say nothing; it now logs one Warning per family, style and weight it had to substitute: Font family 'latolatin' has no normal face of weight 700; drawing its weight 400 face instead. For real bold, add a bold face under your family's name with @font-face (font-weight: bold) as above.

Variable fonts render at their default weight for every weight you ask for. The default font engine calls FT_New_Face and never sets a variation axis, so one variable file cannot serve font-weight: 400 and 700 differently — you get the default instance twice. Ship static instances, one file per weight. Do: put your faces under your project's Content/DevUI/, declare them with root-relative src, and name the family in your sheet. The plugin's own LatoLatin ships with its OFL license under Content/DevUI/fonts/.

6. Style resolution cost jumps after adding one selector. Cause: a bare attribute selector ([disabled] { … } with no element/class anchor) is matched against every element on every resolution — measured at ~2 ms on the research workload (docs/research/2026-07-29-webui-middleware.md:94). The facade-specific half: JS classList writes never write the class ATTRIBUTE, so [class…] selectors lie under classList-driven state (Web/packages/cli/lib/lint.mjs:33-57). Do: anchor attribute selectors (button[disabled]); the lint rule flags bare ones.

7. The first frame with font-effect: glow takes milliseconds. Cause: effect-glyph generation is the measured spike class — up to 32.5 ms on large glyph sets (research :94-95), ~4.2 ms on the reference HUD's first Record (docs/passport/2026-08-vacuus-perf-passport.md, Exp-GLYPH-WARMUP). Do: nothing lands on the game thread — the spike is UI-thread, before first publish (arch spec §9's warm-up: the load IS the warm-up). Budget effect-heavy styles at document load, not per frame; see perf-guide.md.

8. A layout-thrashing document costs 5–16 ms per frame. Cause: measured RmlUi pathology on documents that force full relayout every frame (research :94-95). Do: animate transform and opacity (no layout), not left/top/width; see the blip idiom in perf-guide.md.

8a. FIXED — clipping under a transform (and under border-radius) works. It costs one stencil buffer per view, and only for views that use it. This entry used to be a named v1 limitation: a transform anywhere on the clipping chain silently disabled all clipping beneath it, and overflow: hidden|auto|scroll clipped nothing at all. That is no longer true, and the note is kept rather than deleted because the shape of the old failure is worth knowing if you are reading older material.

What was happening: RmlUi turns the scissor off whenever a transform is active on the clipping chain — if (transform) disable_scissor_clipping = true;, unconditional (Source/ThirdParty/RmlUi/Source/Core/ElementUtilities.cpp:174-175), because a transformed element's geometry may project anywhere and a screen-space rectangle can no longer describe it. The replacement it emits instead is a clip mask (:162-169, whenever has_border_radius || (transform && has_clipping_content)), and the replayer used to skip the two clip-mask commands. So the original clipping was switched off and the replacement never landed.

One correction to the old entry, because it overstated half of itself. It used to say the same sentence applied to border-radius on a clip container with no transform. It did not. Three lines below the one everyone was citing, RmlUi says: "If we only have border-radius then we add this element to the scissor region as well as the clip mask… However, when we have a transform, the element cannot be added to the scissor region" (:171-175). So a rounded clip container kept its scissor and still clipped rectangularly — only the four corner arcs went unclipped, measured at 11.7 differing pixels on the plugin's own demo. Cosmetic, not a screenful. Only transform disabled clipping outright.

The replayer now attaches a stencil target to the replay pass and honours both commands (Source/VaCuusRender/Private/VaCuusReplayRenderer.cpp, EnableClipMask / RenderToClipMask). transform: scale() on a root wrapper — the cheap way to author against a fixed 1920×1080 surface here, because there is no calc() — no longer costs you every scroll container in the document. (After 1.0.3, dp follows the DPI curve — setup.md §2, "Binding and input rules", rule 6 — so authoring in dp is the other way to keep sizes resolution-independent, with no wrapper at all.)

What it costs, since it is not free. The stencil is allocated lazily: a view whose document never takes the mask path never allocates one, and stat vacuus's Clip Mask Draws reads 0 for such a document. A view that does take it pays one depth-stencil target at the view's extent and the view's vacuus.ViewSampleCount, permanently:

vacuus.ViewSampleCountstencil, per view at 1920×1080
1 (default)7.91 MiB
215.82 MiB
431.64 MiB
863.28 MiB

Same table as the MSAA companion target's, for the same reason: same extent, same sample count, same bytes per sample. The two add up if you run both. See perf-guide.md.

Two things still worth knowing.

  • A rounded clip container takes the mask path even with no transform at all (has_border_radius || above), so border-radius on a scroll container is what most often turns the allocation on.
  • The perf advice has not changed and was never really about clipping: for long lists, deleting rows still beats clipping them, because a clipped scrollback still records every row into the command stream ("Smaller standing DOM", perf-guide.md). Clipping now works; it was never free.

8b. opacity does NOT establish a group. A child that sets its own opacity escapes its ancestor's completely. Symptom: you fade a panel out and its contents stay. Worst case, and the one that cost real time: a plate at opacity: 0 with 18 icons at opacity: 0.9 inside it photographs as eighteen lit glyphs floating on nothing. It reads as a z-order or decorator bug, because the one property you would suspect is the one you already set to zero. Cause: in CSS, opacity creates a group — the subtree is composited to its own buffer and that buffer is then faded, so a child at opacity: 1 inside a parent at 0.5 renders at 0.5. RmlUi has no such buffer. opacity is a plain inherited property (Source/ThirdParty/RmlUi/Source/Core/StyleSheetSpecification.cpp:351, inherited = true) that each element multiplies into its own colours at paint time — background and borders at ElementBackgroundBorder.cpp:166-173, text at ElementText.cpp:371-374, every gradient and shader decorator at DecoratorGradient.cpp:140, :265, :434, :631 and DecoratorShader.cpp:42. Inheritance means copy, not compose: ComputeValues copies the parent's inherited block wholesale (ComputedValues.h:394, inherited = parent.inherited) and a local declaration then overwrites it (ElementStyle.cpp:1247, values.opacity(p->Get<float>())). Nothing anywhere multiplies the two together. Do, and the right answer differs by what the child is:

  • Do not redeclare opacity on a descendant if any ancestor animates or toggles its own. Inherit it — that is the case RmlUi gets right, and it is free.
  • Images, <progress>, and image/tiled/ninepatch decorators: use image-color for the child's own fade. It is multiplied by the inherited opacity rather than replacing it (Elements/ElementImage.cpp:178, Elements/ElementProgress.cpp:222, DecoratorTiled.cpp:80, DecoratorNinePatch.cpp:40 — all image_color().ToPremultiplied(computed.opacity())). This is what the 2d6 demo's fix used.
  • Text and solid fills: fade with the alpha channel of color / background-color instead of with opacity, for the same reason — ToPremultiplied computes alpha * opacity (Include/RmlUi/Core/Colour.h:89-98), so an alpha byte is the element's own and composes with what it inherited instead of replacing it.
  • If you genuinely need group semantics, give the group a single opacity and keep every descendant silent about it. There is no way to nest two.

Hosting and input ​

23. The document is on screen, looks right, and is completely dead to input. Symptom: it renders, animates and retranslates, and not one pointer event reaches it — no :hover, no clicks, no wheel. Nothing is logged, by the engine or by this plugin, because nothing went wrong: the events were delivered, just not to you. Most likely on a project whose first VaCuus document is also its first UI. Cause: the game viewport owns the pointer capture and your game never said otherwise — and no game code is needed for that to happen. Unreal's shipped defaults are bCaptureMouseOnLaunch = true and DefaultViewportMouseCaptureMode = CapturePermanently_IncludingInitialMouseDown (Engine/Private/UserInterface/InputSettings.cpp:40,49), which UGameViewportClient::Init copies onto the viewport (Engine/Private/GameViewportClient.cpp:535). Once a capture exists, Slate stops asking what is under the cursor: ProcessMouseButtonDownEvent builds the path from GetCaptorPath and delivers the click to that path's last widget (Slate/Private/Framework/Application/SlateApplication.cpp:5125-5128), so the hit test that would have found your document never gets to decide the target. Moves and the wheel go the same way — RoutePointerMoveEvent routes with FToLeafmostPolicy(MouseCaptorPath) (:5610,5630) and the wheel takes the captor path at :6023-6025; the move path still runs a hit test, but only to work out enter/leave. Your widget's handlers are not called, whatever its visibility or Z-order says. This was observed before it was read: with GameOnly, a synthesized move over a demo button came back HANDLED — by the captor — while RmlUi's hover never changed (Source/VaCuusRender/Private/VaCuusRender.cpp, SetUIInputMode, which is why the plugin's own demos call it). Do: put the local player controller into FInputModeGameAndUI while your UI is up, and back when it goes away. The line that actually fixes it is inside that mode, not in the name: ApplyInputMode calls SlateOperations.ReleaseMouseCapture() and downgrades the viewport to EMouseCaptureMode::CaptureDuringMouseDown (Engine/Private/PlayerController.cpp:6260,6265).

cpp
FInputModeGameAndUI Mode;
Mode.SetLockMouseToViewportBehavior(EMouseLockMode::DoNotLock);
Mode.SetHideCursorDuringCapture(false);
PlayerController->SetInputMode(Mode);
PlayerController->SetShowMouseCursor(true);   // separate switch — neither implies the other

GameAndUI rather than UIOnly, so clicks your UI does not claim still reach the game. The plugin will not do this for you on purpose: a game decides its own input mode, and a VaCuus widget hosted inside an existing UMG tree correctly inherits whatever the game already set. It is only a project's first piece of UI that has nobody to inherit from. (Engine line numbers are 5.6; the code at each of them is identical in 5.8.)

24. Drag'n'drop: the four surprises, in the order they will find you. The working reference is the shipped demo — vacuus.DragDemo (Content/DevUI/drag_demo.rml/.rcss/.js), proven end-to-end by VaCuus.Js.DragDrop — but each surprise costs less read here first:

Plain drag: drag gives you no drop events at all. Of the five RCSS drag values, only drag-drop and clone enable dragover/dragout/dragdrop/dragmove (Source/ThirdParty/RmlUi/Source/Core/Context.cpp:692 sets drag_verbose for exactly those two); with drag you get dragstart/drag/dragend and nothing else, silently. The failure mode is a drag that visibly starts and can never land.

dragdrop fires on the drop TARGET, not on what you dragged — and in JS the dragged element is not in the event. RmlUi passes the source as the drag_element void*, which the JS bridge deliberately drops with the other non-convertible variants (Source/VaCuusJs/Private/VaCuusJsEvents.cpp:44-49). Capture the source yourself in dragstart; that variable is the only reliable handle. The release order over a target is dragdrop → dragout → dragend (Context.cpp:760-775), and dragend fires on the source even when the drop landed on nothing — make it your cleanup point.

Nothing highlights a drop target for you. The library's single drag pseudo-class is :drag, set on the ghost clone only (Context.cpp:1504); sources and targets get no state at all, and ordinary :hover keeps firing on targets mid-drag. Target feedback is therefore your handler's job (the demo adds drop-ok/drop-bad classes from dragover). Note the events are dispatched per element entering or leaving the drag-hover chain and they bubble, so a slot hears its occupying item's transitions too — filter highlights on ev.target === ev.currentTarget, but do NOT filter dragdrop, which lands on the occupant and reaches the slot only by bubbling.

Do not reparent the dragged element inside dragdrop. Moving an attached node goes through RemoveChild, the detach reaches Context::OnElementDetach, and its drag branch SILENTLY cancels the drag — dragend never fires and whatever cleanup you hung on it never runs (Source/ThirdParty/RmlUi/Source/Core/Element.cpp:2129-2133 → Context.cpp:1150-1159). Validate in dragdrop, apply the move in dragend, where the same cancellation has nothing left to kill. The demo's header carries the full argument.

Two smaller facts worth knowing before they are questions: there is no movement threshold — dragstart fires on the first ≥ 1 px move with button 0 held (Context.cpp:1290) — and a drag by touch is the same machinery, because the touch verbs synthesize button-0 mouse events (Context.cpp:916-919). A drag whose cursor leaves every interactive rect keeps working because the widget holds Slate pointer capture from the press; that is SVaCuusWidget's capture gate, not the snapshot, and it is what makes dragging between two panels across empty screen possible.

25. A loading screen built on VaCuus shows nothing while the level loads. Symptom: a UVaCuusWidget inside the engine's stock loading screen — handed to the movie player as FLoadingScreenAttributes::WidgetLoadingScreen, or a PreLoadScreen widget — draws nothing for the whole LoadMap and appears only once the load returns. Nothing is logged. PIE never shows it, because PIE runs no movie player. (Before SVaCuusWidget::Tick learned to skip this thread, the same setup killed a packaged game at its first loading screen: Assertion failed: IsInGameThread() in UVaCuusView::Resize, on SlateLoadingThread1.) Cause: while a level loads, the movie player paints that widget on a Slate thread of its own (MoviePlayer/Private/DefaultGameMoviePlayer.cpp:935 → :407-409, MoviePlayerThreading.cpp:168), and SWidget::Paint ticks it there (SlateCore/Private/Widgets/SWidget.cpp:1505-1511). The widget skips that tick — all of it is game-thread work — and keeps compositing whatever the view last published. A UVaCuusWidget, though, creates its view at 0x0 and takes its size from its first tick (Source/VaCuusRender/Private/VaCuusUMGWidget.cpp:69-76), and an unsized view records nothing (Source/VaCuusRender/Private/Tests/VaCuusUnsizedDrainTest.cpp:44). A widget created for the loading screen gets its first game-thread tick only after LoadMap returns, so until then there is no frame to composite. This was observed in a packaged game whose movie-player screen is a UVaCuusWidget: the screen's view loaded its document at (0x0) and recorded no frame before the load finished. Sized as below, the same view recorded its first frame inside LoadMap, and the screen was up for the whole load. Do: size the view yourself, on the game thread, before its document loads — the load carries the size along (Source/VaCuus/Private/VaCuusView.cpp:181). The movie player draws at the client size of its window (DefaultGameMoviePlayer.cpp:384), and that window is the game's (:239, :300):

cpp
if (const UGameEngine* GameEngine = Cast<UGameEngine>(GEngine))
{
    if (const TSharedPtr<SWindow> Window = GameEngine->GameViewportWindow.Pin())
    {
        const FVector2D Size = Window->GetClientSizeInScreen();
        View->Resize(FIntPoint(FMath::RoundToInt32(Size.X), FMath::RoundToInt32(Size.Y)));
    }
}

The game viewport is no substitute: at the session's first load neither UGameViewportClient::GetViewportSize nor UGameViewportClient::GetWindow() gave a size there. Queued commands wake the UI thread by themselves (Source/VaCuus/Private/VaCuusUIThread.cpp:976-977), so the document is laid out and drawn during the load. What stays still is everything the game drives: the per-frame pulse is UVaCuusSubsystem::Tick → PublishAndPulse (Source/VaCuus/Private/VaCuusSubsystem.cpp:262), which does not run inside LoadMap, so model updates — and a spinner fed from one — resume only when the load returns. An RCSS animation needs that pulse too. Do not: drive the view from anything else Slate runs on that thread. Your own widgets tick there too — an SWidget subclass's Tick, a UUserWidget's NativeTick (UMG/Private/Slate/SObjectWidget.cpp:128) and the Blueprint tick it routes all arrive by the same SWidget::Paint path — and every mutator on UVaCuusView is game-thread-only: Resize, UpdateModel, LoadDocument, BindModel, CallJs, ExecuteScript, SetVisible, Close. This is how the packaged game above died in the first place: UVaCuusView::UpdateModel, called from the game's own loading-screen tick code, on SlateLoadingThread1. Guarding that one call only moved the crash on to the widget's own tick, which is what the fix above answers — your code needs the guard whether or not the plugin has one. Use IsInGameThread(), and use it for the reason that outlives your editor build: in Development the view's assertion catches you, but check() compiles out in Shipping (Source/VaCuus/Private/VaCuusView.cpp:328), and what is left is a second producer on a single-producer command queue (Source/VaCuus/Private/VaCuusUIQueues.h:338-340): a corrupted queue with no assertion and — unlike #14 — no log line standing in for it. The configuration that ships is the one that says nothing. (Engine line numbers are 5.8.)

26. A UI element pinned to a world object trails that object by one frame — invisible at 60 fps, half a screen at 15. Symptom: a marker over a vehicle, a nameplate over a character, a minimap arrow — anything whose screen position the host projects through the camera — sits behind where it belongs while the camera pans, and snaps into place the moment the camera stops. It reads as jitter rather than as a fixed offset, because the size of the error IS the frame time: nobody sees it at 60 fps and it is half the screen at 15. Turning frame generation off appears to help and fixes nothing — that only changes the frame time. Nothing is logged, and the host's own projection math is correct. Cause: UVaCuusSubsystem is an FTickableGameObject, so its Tick() runs from FTickableGameObject::TickObjects (LevelTick.cpp:1821) — BEFORE this frame's camera update (PlayerController->UpdateCameraManager, :1847) and before FWorldDelegates::OnWorldTickEnd.Broadcast (:2061). A host can only project against a final camera after :1847, so its model writes land after this subsystem has already published and pulsed for the frame. UpdateModel() only marks fields dirty (Source/VaCuus/Private/VaCuusView.cpp:464); publishing is a separate step (:652). The write therefore rides the NEXT frame's pulse — every frame, indefinitely. Do: take the publish over. TakeFramePump() when your UI layer comes up, PumpUIFrame() once per frame once this frame's models are written, ReleaseFramePump() when the layer goes away:

cpp
// once, when the layer is created
VaCuusSubsystem->TakeFramePump();

// every frame, from FWorldDelegates::OnWorldTickEnd -- after the panels have projected
for (TUniquePtr<IHudPanel>& Panel : Panels)
{
    Panel->Tick(Frame, *View);   // the UpdateModel() calls happen in here
}
VaCuusSubsystem->PumpUIFrame();

// once, when the layer is removed
VaCuusSubsystem->ReleaseFramePump();

Ownership is ref-counted, so split screen — two local players, one game-instance subsystem — works: the tick resumes publishing only when the LAST owner releases, and one player's pump publishes every view, the other player's included. While the pump is owned, Tick() still polls view status and drains the write router; only the publish and the pulse move. If several of your systems write models at the end of the frame, have each of them pump at the end of its own work rather than electing one — publishing is free when nothing is outstanding and the wake coalesces. Do NOT rely on the order of your OnWorldTickEnd listeners to make one pump serve all of them: that delegate broadcasts in reverse registration order and compacts with RemoveAtSwap, so the order changes when an unrelated system subscribes. The exception is a platform with no worker thread, where the UI frame runs inline inside PumpUIFrame() and N pumps are N frames — there, pump once. Do not: gate PumpUIFrame() on the same condition that gates your panel logic. This subsystem ticks while the game is paused on purpose (Source/VaCuus/Public/VaCuusSubsystem.h:87), so a pump skipped on paused frames freezes the UI for the whole pause — including the pause menu that is meant to be on screen. Tick your panels under whatever gate they need; pump unconditionally. And know what the failure looks like, because the hand-over does NOT time out: an owner that stops pumping without releasing stops the UI for everyone and gets one LogVaCuus warning naming the frame it stopped on, then silence. The tick deliberately does not take the publish back — doing so would quietly restore the one-frame staleness above, and that is invisible at 60 fps where a frozen UI is not. (Engine line numbers are 5.8.)

Data binding and JS ​

9. Your data model binds to nothing, one Error at load time. Cause: data-model="x" is resolved EXACTLY ONCE, in Element::SetParent, when the body is parented into the context (Content/DevUI/m3_demo.rml:7-14 documents it with the RmlUi cite: Element.cpp:2202-2219). A model created after document load attaches to nothing. Do: bind models BEFORE LoadDocument; the command queue being FIFO from one producer is what makes that ordering hold across the thread boundary.

10. Your data-for list renders one extra invisible row — or styling misses rows. Cause: the element carrying data-for is a hidden clone TEMPLATE, not the first row — DataViewFor::Initialize sets display: none on it and every generated row is a clone inserted before it (m3_demo.rml:71-79, citing DataViewDefault.cpp:479, :535). Do: hang row styling off the template's own class list; never expect the template element itself to render.

11. Writing {{Health}} from JS shows literal braces. Cause: the brace-injection contract — a text node written through the facade renders literally, never as a binding (M5 spec §7:298-301; the facade test proves both directions). Do: this is a security property, not a bug. Bindings come from the document; JS writes are data. Route through innerRML only when you mean markup.

11b. A style your JS wrote inline disappears when the component framework re-renders that element — and a change gate that outlives the element makes it permanent. Cause: OBSERVED, mechanism deliberately not asserted. In the 2d6 demo a applyScale() wrote transform: scale(1.3333) onto #stage and gated later writes on a data-scale ATTRIBUTE it wrote beside it. On two screens the router changed screen in the same frame and re-rendered the subtree under #stage: the JS log shows the transform WAS written (stage: view 2560x1440 -> scale(1.3333), frame 1), the measured tab-bar card edges are the 1920-space ones in a 2560-wide view, and the attribute survived while the inline style did not — so the gate then suppressed every rewrite and the document stayed unscaled in the corner of the view for the rest of the session. Preact's diffProps should not touch a style prop that neither vnode carries, so a definition-dirty path in RmlUi is the other candidate; nobody has chased it, and this entry does not pretend otherwise. Do: two rules, and the second is the load-bearing one. (a) Put JS-owned properties on an element your component tree never renders into. The ElementDocument is the natural one — document.style is reachable from JS and no framework owns it. (b) Never gate a write on state whose lifetime differs from the thing it gates. A module-scope variable outlives re-renders correctly; an attribute or class on the same element you are writing to does not. The symptom is silence — no warning, no error, one missing property, forever — which is why it costs a session to find rather than a minute.

11c. Calling into your UI with ExecuteScript + Printf is a code-injection bug in your own game. Cause: ExecuteScript takes SOURCE. Passing a value through it means interpolating that value into source, so a string carrying an apostrophe stops being an argument and becomes code — Printf(TEXT("f('%s')"), PlayerName) with a name of ');doSomething();// runs doSomething(). Player names, chat lines, quest titles and anything else a server hands you are exactly the strings this bites on, and the failure is silent: the call still "works". Do: use UVaCuusView::CallJs(FunctionPath, Args) instead. The path is dotted from globalThis (vacuus.onFreeze), the arguments are FVaCuusJsValues, and no source line is ever built — each value crosses as a JSValue and reaches your function as data, so there is no parser downstream for a string to escape into.

cpp
View->CallJs(TEXT("vacuus.onFreeze"), {FVaCuusJsValue::MakeBool(true)});

It also absorbs the typeof f === 'function' guard every hand-written call site needed: a path that resolves to nothing logs one Warning naming it and throws nothing, because a document that has not registered the callback yet is not an error. this inside the callee is the owner of the last segment, exactly as a written vacuus.onFreeze(x) would give. Keep ExecuteScript for what it is for: running SOURCE you wrote, not data you were handed.

12. A <script src> or rcss link 404s with the directory doubled. Cause: src is DOCUMENT-relative — the head handler joins the path against the document's own URL (Content/DevUI/M5Hud/m5_hud.rml:13-18, citing SystemInterface::JoinPath via XMLNodeHandlerHead). From M5Hud/ the bare name is correct; M5Hud/hud_bundle.js doubles the directory and skips the script with one named Error. Do: write paths relative to the document, and read the Error's resolved path when a load is skipped. @font-face's src is the one exception — it is ROOT-relative (#5). The CLI scaffold gets this right: vacuus create emits the bare bundle name.

13. There is no CSS Grid. Cause: RmlUi is flex-first (research :76; arch spec §1 non-goals — the same market bar as Gameface). Do: flex layouts; the CLI templates are flex-first. Grid is a candidate upstream contribution, not a v1 promise.

13a. Atomics does not exist on Windows — and SharedArrayBuffer does, so the obvious feature test lies. Measured on Win64 2026-08-03: typeof Atomics is "undefined" while typeof SharedArrayBuffer is "function". On Linux and macOS both are present. Cause: the vendored quickjs-ng guards its whole atomics feature on !__STDC_NO_ATOMICS__ (quickjs.c:73), and MSVC defines __STDC_NO_ATOMICS__ unless /experimental:c11atomics is passed — which VaCuus deliberately does not pass, rather than opt a shipped module into an experimental compiler switch (VaCuusJs.Build.cs carries the decision). SharedArrayBuffer is not behind that guard, which is why the two come apart. Do: feature-detect Atomics itself, never SharedArrayBuffer as a proxy — if (typeof Atomics !== 'undefined'). The proxy test passes on Windows and then Atomics.load throws a TypeError, so a script written that way works everywhere you develop and fails on the platform most of your buyers ship to. If you need cross-thread coordination, note that VaCuus already runs every document on one process-wide UI thread, so a JS-visible atomic is rarely the tool you want.

21. You push a new translation table and half the screen changes. Cause: the two readers do not have the same timing, and this is by design rather than a defect. RmlUi translates element text once, when the document is parsed, so <div>hud_health</div> keeps the language it was loaded in forever. Text written {{ t.hud_health }} inside a data model re-evaluates on the next UI frame, and vacuus.translate() always reads the newest table. So a mixed document visibly splits in two on a language switch. Do: decide per string. Plain markup is the fast path and stays the default; opt the strings that must change in place into {{ t.key }}. If you keep parse-time strings, a switch costs ClearAssetCachesAndReloadAllViews — which re-mounts JS from the module's top level, so open tab, scroll position and timers all reset, on the very screen the player is using to change the language. vacuus.LocDemo then vacuus.LocDemo.Lang fr shows both halves side by side in about ten seconds. Note the live route's keys are restricted to [A-Za-z][A-Za-z0-9_.]* — no hyphens, no leading digits — because they are parsed as data expressions. A key that does not fit simply stays parse-time. Full treatment: localization.md.

22. A model containing FText shows the old language after a culture change. Cause: an FText field is resolved to a culture-invariant string once, on the game thread, inside UpdateModel — which is what keeps the UI thread away from FTextLocalizationManager and makes the design thread-safe at all. The projected text has no text id left, so it can never re-resolve itself. The plugin cannot re-push for you either: it holds no pointer to your live struct. It will however tell you. A model carrying FText that sees no update in the 60 UI frames after a table change gets one Warning naming the model and its type:

LogVaCuus: Warning: VaCuus model 'hud' (FMyHudModel) carries FText and has NOT been
re-pushed in the 60 frames since the translation table changed, so its text is still in
the previous language.

A model you push every frame — which is what the rest of the system assumes — never triggers it. Do: call UpdateModel every frame, or re-push from UVaCuusSubsystem::OnTranslationTableChanged.

Engine, cook and packaging ​

14. Shipping builds never assert on RmlUi contract violations — but the log still names them. Cause: RmlUi's asserts compile out of shipped configs; its Error/Warning log lines do not (commit b08bd34; the routing is Source/VaCuus/Private/VaCuusSystemInterface.cpp — RmlUi log → LogVaCuus). Do: treat LogVaCuus: Error: [Rml] … in any build as the assert you didn't get. Zero such lines is an acceptance gate the plugin's own demos hold themselves to.

15. Restarting PIE does not give you a clean stylesheet slate. Cause: RmlUi's StyleSheet/Template caches are process-global and outlive PIE (bd memory rmlui-caches-outlive-pie-2026-07-30 — found the hard way in M2, where a cache bug survived review because the caches expose no observable). Do: edit-and-watch (live reload invalidates properly) or vacuus.ReloadUI; do not expect a PIE restart alone to drop cached styles in the same editor process.

16. An identifier that differs only by case works uncooked and breaks cooked. Cause: FName case-collision — in cooked builds the first registration wins and later same-spelled-differently names silently take its casing (bd memory fname-cooked-first-registration-wins). The other spelling need not be yours: a model member Id reads back as ID in a cooked build where anything registered ID first. Struct members are matched byte-exact and then ignoring case, so {{ row.Id }} resolves either way (Source/VaCuus/Private/VaCuusDataVariable.cpp, FVaCuusStructDefinition::Find). The editor, where a member's spelling is its author's, logs a match that needed the fold once per struct as resolved 'id' to its member 'Id' ignoring case — that is a real typo, fix it. A model's top-level field names are matched by RmlUi byte-for-byte (Source/ThirdParty/RmlUi/Source/Core/DataModel.cpp:234) and are not covered — a Could not find variable name warning that only a cooked build logs is this. Bundle paths dodge this by construction: they are normalized lowercase (Source/VaCuus/Public/VaCuusBundle.h, NormalizePath — the one definition). Do: treat UI paths and model names as case-insensitive-unique; never distinguish two identities by case alone; rename a top-level field that stops resolving cooked.

17. The standalone binary exits within seconds on uncooked content — no log, exit 1. Cause: a non-editor target has no compiled global shader library and cannot build one from uncooked data (bead akj.6.17, reproduced in the M6 sweep — the failure writes no project log at all, docs/research/m6-api-notes/p2-sweep.md §4). This is stock UE behavior, not a plugin defect. Do: the supported matrix is — uncooked content → UnrealEditor -game; the standalone game binary → cooked/staged builds only. Every recipe in the plugin's docs already follows this.

18. You edit a file in PIE, the reload fires, and the screen shows the old bytes. Cause: a mounted bundle shadows the loose tree — the VFS serves the PACKED copy of anything the bundle contains, and live reload never applies to bundle-served content (the watcher watches loose roots only). The trap is loud, not silent: the watcher logs one Warning per shadowed file naming the bundle (Source/VaCuusEditor/Private/VaCuusLiveReload.cpp:472-497). Do: what the Warning says — vacuus.Bundle.Enable 0 unmounts (loose files serve again); vacuus.Bundle.Enable 1 re-packs the tree with your edit in it.

19. -legacyiterative with ZenStore off ships a stale bundle, silently. Cause: the legacy iterative cook cannot store FCookDependency data — the cooker says so itself and falls back — so a tree edit (or worse, a deletion) does not repack the bundle; the cooked bundle still contains the deleted file (docs/research/m6-api-notes/bundle-cook-experiments.md, Exp-COOK-FILEDEP ZenStore OFF: "Keeping 586. Recooking 0." with a deleted file still packed). This is the ONE stale-bundle configuration found; everything else either recooks correctly (ZenStore on, incremental — exactly the bundle package recooks on a tree edit) or recooks everything (ZenStore off, default full cook — slow but correct). Do: with bUseZenStore=False, do not pass -legacyiterative on a project that cooks UI bundles. The safe default full cook is what you get without it.

20. A silent exit 127 when you enable a stat GROUP means a STALE module binary, not a stat bug. Symptom: your editor or -game session exits instantly — no callstack, no crash dialog, exit status 127 — the moment you enable a stat GROUP (stat vacuus, stat slate, stat scenerendering), while stat fps is fine (it draws its own counter and never master-enables collection). Cause, and it is neither this plugin nor your machine's libc: in a built-from-source engine tree, a module .so left over from an older build can import symbols the current libUnrealEditor-Core.so no longer exports. The dynamic linker binds lazily, so nothing fails at load — the process dies at the first call into that module, and enabling a stat group is a reliable way to make that call happen, because engine modules tick SCOPE_CYCLE_COUNTER scopes and a master-enable is what first sends those messages. On the machine this was diagnosed on (2026-08-03) it was libUnrealEditor-XMPP.so from four months earlier, importing FLLMScope's constructor and destructor, which today's Core exports only as FLLMScopeDynamic. Do: read stderr, not the log. The .log file ends mid-line and shows nothing, but the process prints one line to the terminal that names the culprit exactly:

symbol lookup error: .../libUnrealEditor-XMPP.so: undefined symbol: _ZN9FLLMScopeD1Ev

Compare that .so's date with libUnrealEditor-Core.so; if it is older, delete it and rebuild. Deleting it was enough here — the module was not part of the current target at all, only left behind in the manifest. An Installed (Launcher) engine cannot hit this, because you never rebuild Core underneath its modules; it is a from-source dev-loop hazard, and a packaged build is immune by construction. Do also: measure VaCuus with its own instrument regardless — vacuus.M1HUD.PerfLog 1 (all scopes, publish/skip ratios, per-window means and p99, in every configuration including packaged Shipping via -VaCuusPerfLog). It is what the performance passport was measured with, and it does not depend on the stats system being enabled at all.
